TECHNICAL SPECIFICATIONS |
|
| Model
|
LUX B
|
| Type
|
Hydraulic
|
| Control Panel
|
ALGOR AC A
|
| Operator
|
Irreversible
|
| Power Supply
|
230V~+-10%, 50Hz single phase
|
| Leaf Weight
|
up to 3000N (~300kg)
|
| Leaf Length
|
up to 2m
|
| Absorbed Power
|
250W
|
| Thermal Protection
|
Intergrated
|
| Rod Working Stroke
|
270mm
|
| Rod Speed
|
14mm/s
|
| Opening / Closing Speed
|
17s
|
| Impact Reaction
|
Hydraulic clutch
|
| Type of Lock
|
Hydraulic on closing
|
| Manual Release
|
Release key
|
| Operating Cycle
|
Very intensive use
|
| Environmental Conditions
|
From -10C to +60C
|
| Degree of Protection
|
IP57
|
| Operator Weight
|
87N(~8,7kg)
|
