Staircase dimensions (staircase pitch 65۫) |
||||||||||||||
| C
|
Room height
|
260 |
270 |
280 |
290 |
300 |
310 |
320 |
330 |
340 |
350 |
360 |
380 |
400 |
|
|
Number of steps
|
9 |
9 |
10 |
11 |
11 |
11 |
12 |
12 |
13 |
13 |
13 |
14 |
15 |
| A1
|
Min. opening length
|
80 |
80 |
90 |
90 |
90 |
100 |
110 |
110 |
120 |
120 |
130 |
130 |
140 |
| E
|
Extension clearance
|
170 |
175 |
180 |
185 |
190 |
195 |
200 |
205 |
210 |
215 |
220 |
225 |
230 |
| F
|
Stair foot rest pont
|
140 |
145 |
150 |
155 |
160 |
165 |
170 |
175 |
180 |
185 |
190 |
195 |
200 |
| A2
|
Opening width
|
Independent of length and height: 50-55-60-65-70-75-80-85-90-100
|
||||||||||||
|
|
Step width
|
21 – 26 - 31 – 36 (48 cm on request for A2 ≥ 85cm )
|
||||||||||||
| B
|
Frame width
|
To customer specifications (standard 20 cm)
|
||||||||||||
| D
|
Trap door opening
|
Not required (except for version with handle for opening or closing from above)
|
||||||||||||
