TECHNICAL SPECIFICATIONS |
|
| Model
|
FORB R
|
| Type
|
Hydraulic
|
| Control Panel
|
RIGEL 5
|
| Operator
|
Irreversible
|
| Power Supply
|
230V~+-10%, 50Hz single phase
|
| Door Weight
|
720N = 2,4m2 (2 operators)
|
| Absorbed Power
|
250W
|
| Thermal Protection
|
Integrated
|
| Slowdown
|
Openoing/Closing
|
| Opening / Closing Speed
|
13s + slowdown
|
| Output Revolutions
|
2,4 rpm
|
| Max Torque
|
320N
|
| Impact Reaction
|
Hydraulic clutch
|
| Type of Lock
|
Hydraulic on opening/closing
|
| Manual Release
|
Lever
|
| Operating Cycle
|
Very intensive use
|
| Environmental Conditions
|
From -15C to +60C
|
| Degree of Protection
|
IP20
|
| Operator Weight
|
130N(~13kg)
|
