TECHNICAL SPECIFICATIONS |
|
| Operators
|
P4,5 / P7
|
| Power supply
|
230V~10%, 50 Hz
|
| Absorbed power
|
250 W
|
| Thermal protection
|
integrated
|
| Max leaf weight
|
5000N (~500 kg)
|
| Leaf length
|
4,5m / 7m
|
| Rod working stroke
|
390 mm
|
| Rod speed
|
14 mm*s-1 / 8,3 mm*s-1
|
| Opening time
|
30s / 45 s
|
| Closing time
|
28 s + slow down / 42s + slow down
|
| Slow down
|
Hydraulic on closing
|
| Slow-down stroke
|
20 mm
|
| Impact reaction
|
Hydraulic clutch
|
| Type of lock
|
Electric lock
|
| Control
|
ALCOR AC A
|
| Manual maneuver
|
Reversible + release knob
|
| No maneuvers in 24 hours
|
500
|
| Environmental conditions
|
From -10OC to + 60OC
|
| Degree of protection
|
IP 55
|
| Operator weight
|
122,5 N (~12,5 kg)
|
