TECHNICAL SPECIFICATIONS |
|
| CONTROL PANEL
|
MERAK BM (incorporated)
|
| REVERSIBLE/IRREVERSIBLE OPERATOR
|
Irreversible
|
| POWER SUPPLY
|
230V ~10%, 50 Hz single-phase
|
| BOOM LENGTH
|
6m / 8m
|
| OPENING OR CLOSING TIME
|
6s / 8s
|
| ABSORBED POWER
|
300 W
|
| IMPACT REACTION
|
Electronic torque limiter integrated in the control panel
|
| TYPE OF LIMIT SWITCHES
|
Electronic opening/closing
|
| MANUAL RELEASE
|
Fast key release
|
| OPENING CYCLE
|
Very intensive use
|
| ENVIRONMENTAL CONDITIONS
|
From –100C to +550C
|
| DEGREE OF PROTECTION
|
IP 24
|
| OPERATOR WEIGHT WITHOUT BOOM
|
580 N (~58 kg) / 680 N (~68 kg)
|
