TECHNICAL SPECIFICATIONS |
|
| CONTROL PANEL
|
MERAK BG / BGS (incorporated)
|
| REVERSIBLE / IRREVERSIBLE
|
irreversible
|
| BOOM LENGTH
|
3 m - 6m
|
| POWER SUPPLY
|
24/230V ~10%, 50 Hz single-phase
|
| ABSORBED POWER
|
250 W – 300 W
|
| THERMAL PROTECTION
|
integrated
|
| OPENING OR CLOSING TIME
|
2.5 s - 6 s
|
| SLOWDOWN
|
ADJUSTABLE
|
| TYPE OF LOCK
|
mechanical opening/closing
|
| MANUAL LIMIT SWITCHES
|
electric, incorporated, adjustable (encoder)
|
| MANUAL RELEASE
|
fast release with personalized key
|
| OPERATING CYCLE
|
Intensive
|
| ENVIRONMENTAL CONDITIONS
|
from -10 ۫C to + 55 ۫C
|
| DEGREE OF PROTECTION
|
IP24
|
| OPERATOR WEIGHT WITHOUT THE ROD
|
410N (~41 Kg)
|
