TECHNICAL SPECIFICATIONS |
|
| Model
|
TH7
|
| Doorblade
|
Perimetral anodized aluminium profile
|
| Insulation
|
High pressure injected polyurethane foam 50Kg/m³ (Bayer)-free of CFC and HCFC.
|
| Thickness
|
40mm
|
| Internal and external finishing
|
Plastic laminated in phenolic resin or 18/8 Stainless steel.
|
| Sealing
|
Imperviousness profile of rubber neoprene mounted on an aluminium profile
|
| Fixtures and Fittings
|
External and internal pullers of anodized aluminium
|
| Bottom track
|
Anodized aluminium profile
|
| Track
|
with 45º indentation.
|
| Construction
|
Extruded anodized aluminium with canopy
Pulleys of injected polyamide, with ball bearings Pulleys supports in AISI 304 stainless steel |
| Options
|
Electric automation
Windows: Aluminium profile Silicone profile Flat level Special glass Finishing: Color range to be consulted Sealing Frame |
