TECHNICAL SPECIFICATIONS |
|
| Model
|
ARGO
|
| Control Panel
|
VENERE D (INCORPORATED)
|
| Operator
|
Irreversible
|
| Power Supply
|
230V~+-10%, 50Hz single phase
|
| Absorbed Power
|
240W
|
| Max torque
|
up to 80Nm
|
| Door Dimensions
|
up to 35m2
|
| Thermal Protection
|
Intergrated
|
| Maximum Output Shaft Speed
|
30 rpm
|
| Maximum Output Shaft Revolutions
|
19
|
| Anti Crush
|
Electronic ampere-stop
|
| Type of Limit Switches
|
Electronic with absolute encoder
|
| Manual Release
|
Unlocking with steel cable
|
| Operating Cycle
|
Very intensive use
|
| Environmental Conditions
|
From -20C to +55C
|
| Degree of Protection
|
IP20
|
